Aurora! High-Power Motion Control for LEO & GEO Applications!
The Aurora Servo Drive Is The Answer to Your High-Power Space-Rated Motion Control Applications.
This Radiation Tolerant controller takes the available in a Dual-Axis Configuration and adds more power along with multiple options of feedback while still providing one of the smallest servo drives for space applications on the market today.
Aurora has been field proven in several space applications. Contact Us to see how the Aurora may help you with your application.
Aurora has been field proven in several space applications. Contact Us to see how the Aurora may help you with your application.
The Aurora Radiation Tolerant Dual-Axis Servo Controller
The Aurora has inrush protection, a brake driver and is packaged in a rugged case which does not require additional cooling.
Please download our Aurora Product Brief at the bottom of the page or Contact Us for more information!
- Fully Digital High-Performance Drive
- Software Configurable to drive a Single Motor or Two Independent Motors
- Multiple Feedbacks Included
- Serial Encoder over LVDS
- Resolver
- Hall
- Communication Interfaces
- CAN
- RS-422
- Torque, velocity or position control
- Embedded Motion Controller, Coordinated Motion of 2+ Axis
- User-friendly GUI with Integrated Oscilloscope
- Chassis Cooled
- Motor Type: 3-Phase Permanent Magnet or Optional Stepper Motor
| Bus Voltage Range: | 120V |
|---|---|
| Peak Current: | 10A |
| Output Power: | 1200W |
| Efficiency: | > 95% (full load) |
| Operating Temperature: | – 40 °C to 71 °C |
| Maximum Electrical Speed: | Up to 75,000 RPM |
| WEIGHT: | 1.1 lb. (499g) |
| SIZE: | 6.5” W x 3.38” L x 0.9” H |
