Extreme Thermal Range Servo Control System

ESI Motion’s Vulcan Servo Drive offers the most thermally resistant, high-temperature and fully ruggedized servo control module. The Vulcan line is an integrated solution, with advanced features in a “plug-and-play” capable package. The Vulcan drive marries ESI’s rugged control systems with the equally durable power driver module, then adds integrated EMI filters, inrush limiters, military grade connectors and seals and a fully submersible case. The resulting product is an extremely ruggedized servo control package with unmatched performance.

img-fuild
img-fuild

A Rugged Servo That Can Take The Heat

The Vulcan operates at high-voltages and temperatures up to 121⁰C, making it ideal for defense, energy, oil and gas, aviation, automotive or heavy industrial applications in outdoor, high-temperature, high vibration or other extreme environmental conditions.

Contact Us

If your project could benefit from the Vulcan line of servo drive controllers, or you have further questions about custom configurations or capabilities, we have an engineer ready to work with your team. Give ESI Motion a call or email today to set up a consultation and see how we can help you take your applications to the next level!

Feature highlights include:

  • Shock & vibration tolerant construction
  • Configurable, user-friendly GUI with built-in scope feature
  • High-density DSP controller for single or dual-axis
  • Multiple power driver options
  • MIL-STD-461 EMI filter, active inrush limiter and regen switch

Applications:

  • Airborne sensor
  • Surveillance
  • Wing deployment
  • Armament handling equipment

40+ Configurations

Specifications

BUS VOLTAGE (DC) 24V-610V
PEAK MOTOR CURRENT 65A
TEMPERATURE (AMBIENT) (COOLANT) -40ºC to 121ºC -40ºC to 85ºC
ELECTRICAL SPEED MAX Up to 75,000 RPM
WEIGHT 11.5 lbs (5.2 kg)
MOTOR TYPES DC Brushless, Brushed and Induction
FEEDBACK OPTIONS Sensorless, Encoder, Resolver, Hall
COOLING OPTIONS Liquid
PACKAGING Ruggedized
SIZE 16.3” L x 6.3” W x 3.0” H
