Beetle: Compact & Ultra-Low Weight Single-Axis Sized Servo Drive Module
Feature Highlights Include
- Single-Axis Configuration
- Resolver, Hall, BiSS-C (unidirectional), Quadrature Encoder and Sensorless Feedback
- CAN & RS-422
- Shock/Vibration per MIL-STD-810G:
- Random Vibration 514.7 Category: 16.3 Grms, 15 – 2,000 Hz (0.20 g2/Hz)
- Shock 516.7 Procedure 1: 40G Terminal Peak Sawtooth, 11ms
- Optional Software Design Assurance: DO-178C
- Software Configurable to drive a Single Motor
- ESI PC GUI Compatible
Applications:
- Attack Helicopter / Military Jet
- Unmanned & eVTOL Vehicles
- Defense / Military
- Commercial
Specifications
| Bus Voltage Range: | 22VDC – 300VDC |
|---|---|
| Max Continuous Motor Current: | 20 Amps |
| Max Output Power: | 6 kW |
| Wide Operating Temperatures: | – 40 °C to 71 °C |
| WEIGHT: | 181.4g (6.4oz) |
| SIZE: | 96.5 mm x 50.5 mm x 25.4 mm (3.8” x 1.99” x 1.0”) |
Interested in a 600V or 900V Version?
Downloadable Materials
ESI Motion’s servo drive systems are designed for precision military, aviation, automotive, robotics, and specialized industrial applications where size and weight are critical.
Contact ESI Motion to begin working with our team on your servo drive solution today!
