Versatile High-Density Dragon Servo Drive
An Adaptable Rugged Drive Solution
This versatile servo line is ideal for high performance military, aviation, automotive, and specialized industrial applications operating outdoors, at high temperatures, in high vibration or other extreme environmental conditions.
The Dragon is at home in particularly harsh conditions where flexibility and a wide range of capabilities are required.
Configure The Dragon To Your Exact Servo Specifications
For application specific questions, or to speak with ESI about designing a modified drive based on the Dragon, call or email ESI Motion. Discover what makes our ruggedized servo drives the best choice for extreme conditions and configure the perfect servo drive controller at ESI Motion.
Feature highlights include:
- High-density DSP Controller for Single or Dual-Axis
- Multiple Power Driver Options
- MIL-STD-461 EMI Filter
- Active Inrush Limiter
- Regen Switch
- Resolver, Encoder and Sensorless Feedback
- Configurable, User-Friendly GUI with Built-In Scope Features
Applications:
- Winch Control
- Countermeasure Electronics
- Special Mission Equipment
- Vehicle Modernization
- Environmental Systems
750+ Configurations
Specifications
| BUS VOLTAGE (DC) | 24V – 610V |
|---|---|
| PEAK MOTOR CURRENT | Up to 80A |
| OUTPUT POWER | 12kW |
| TEMPERATURE | -40ºC to 71ºC |
| ELECTRICAL SPEED | Up to 75,000 RPM |
| WEIGHT CHASSIS COOLED SINGLE CHASSIS COOLED DUAL | 6.4 lbs (2.9kg) 8.6 lbs (3.9kg) |
| MOTOR TYPES | Brushless, Brushed and Induction |
| FEEDBACK OPTIONS | Sensorless, Encoder, Resolver, Hall & BiSS-C |
| PACKAGING | Ruggedized |
| SIZE SMALL LARGE | 11.3” L x 7.0” W x 2.7” H 13.8” L x 7.0” W x 2.7” H |
