Insane Power Density & Durability

The Hyperion servo drive offers an incredibly high-powered, fully integrated “plug-and-play” control solution. Developed specifically for high-power density markets, the Hyperion drive is ideal for energy recovery, hybrid vehicles and other applications.

As with all our drives, they can be modified to suit your application or off-the-shelf. If you need a fully customized solution, please contact us!

img-fuild

Maximum Power Density & Durability

With its compact casing, the Hyperion offers unrivaled power density ratings of up to 100 Kilowatts and can handle up to 800 volt systems and motors up to 240,000 RPM. As with other ESI systems, the Hyperion is resilient to harsh environments as well, and remains efficient throughout a wide temperature range as well as being movement and shock tolerant.

Typical use for servo drives of this caliber include high speed automotive use, like performance race cars, as well as energy recovery and control platforms such as solar power grids. In many cases a larger, heavier unit would reduce efficiency, impede performance, or simply not survive the demanding environment.

Put Hyperion

Put Hyperion To Work For You

If your application requires a servo drive controller that can handle high speed and power without the bulk, the Hyperion’s design may be just the solution you are seeking. Contact ESI Motions team to discuss your specific needs, and we will help you design and build a drive system unlike any other. Never settle for moderate performance, demand the extreme capability of ESI’s ruggedized servo drive systems and solutions!

Feature highlights include:

  • Incredible Output Power to 100kW
  • Revolutionary High-Speed Performance to 240,000 RPM
  • Highly Compact Size of Roughly 200 Cubic Inches
  • Shock and Vibration Tolerant Construction
  • Configurable, User-Friendly GUI with Built-In Scope Features

Applications:

  • Energy Recovery Systems (ERS)
  • Vehicle Electrification
  • Hybrid Electric Platforms
  • Power Systems Management
  • Environmental Cooling Systems

4 Configurations

Specifications

BUS VOLTAGE (DC) 400V-800V
PEAK MOTOR CURRENT 125A & 250A
OUTPUT POWER MAX 100kW
TEMPERATURE -40ºC to 75ºC
ELECTRICAL SPEED MAX Up to 240,000 RPM
WEIGHT 9.8 lbs (4.4 kg)
MOTOR TYPES DC Brushless, Brushed and Induction
FEEDBACK OPTIONS Sensorless and Resolver
COOLING OPTIONS Liquid
PACKAGING Ruggedized
SIZE 10.3” L x 5.9” W x 4.0” H

Downloadable Materials
