Comet: Up to 5Amps, 120VDC, Dual-Axis, Radiation Tolerant Stepper Motion Controller
The Comet Servo Drive Is The Answer to Your High-Power Space Applications.
This Servo Drive Is Perfect for LEO, GEO, MEO, Lunar and Deep Space Motion Control Applications.
This Radiation Tolerant controller takes the available in a Dual-Axis Configuration and adds more power along with multiple options of feedback while still providing one of the smallest servo drives for space applications on the market today.
Contact Us to see how the Comet may help you with your application.
Contact Us to see how the Comet may help you with your application.
The Comet Radiation Tolerant Dual-Axis Servo Controller
The Comet has inrush protection, a brake driver and is packaged in a rugged case which does not require additional cooling.
Please download our Comet Datasheet at the bottom of the page or Contact Us for more information!
Comet Features
- Fully Digital High-Performance Drive
- Software Configurable to drive a Single Motor or Two Independent Motors
- Multiple Feedbacks Included
- Serial Encoder over RS-422
- Hall
- Optional Resolver
- Communication Interfaces
- CAN
- RS-422
- Torque, velocity or position control
- Embedded Motion Controller, Coordinated Motion of 2+ Axis
- User-friendly GUI with Integrated Oscilloscope
- Chassis Cooled
Comet Specifications
| Motor Types: | Stepper |
|---|---|
| Bus Voltage Range: | 120V |
| Peak Current: | 10A |
| Output Power: | 1200W |
| Efficiency: | > 95% (full load) |
| Operating Temperature: | – 40 °C to 71 °C |
| WEIGHT: | 1.1 lb. (499g) |
| SIZE: | 6.5” W x 3.38” L x 0.9” H |
