Rogue - Rugged Dual-Axis Servo DriveRugged, Flexible, and High-Power Density
ESI Motion’s Rogue Servo Drive provides power house performance in a small, lightweight package. Rogue incorporates our rugged, high-density DSP controller and power driver modules, offers several feedback options, and is packaged in a military-grade submersible case.
An Adaptable Rugged Drive Solution
This versatile servo drive is ideal for high-performance applications operating at high temperatures, in high vibration, or other extreme environmental conditions.
ESI Motion’s servo drive systems are designed for precision military, aviation, automotive, robotics, and specialized industrial applications where size and weight are critical. ESI Motion products are designed and built at our USA facility.
Configure The Rogue to Your Exact Servo Specifications
For application specific questions, or to speak with ESI about designing a modified drive based on the Dragon, call or email ESI Motion. Discover what makes our ruggedized servo drives the best choice for extreme conditions and configure the perfect servo drive controller at ESI Motion.
Feature Highlights Include:
- Fully Digital High-Performance Drive
- MIL-STD-461 EMI Filter*
- Multiple Feedback Options
- Torque, Velocity, or Position control
- Brake Drivers
- Regeneration Controller
- Active Inrush Limiter
- Communication Interfaces of CAN & RS-422
- Software Configurable to drive a Single Motor or two Independent Motors
- Includes configurable, user-friendly GUI with enhanced data collection capability and integrated oscilloscope feature
Applications
- Unmanned Aerial Vehicle
- Aerospace
- Ground/Land
- Sea/Subsea
Specifications:
| Nominal Voltage | 28 VDC |
|---|---|
| Maximum Continuous Output Current | Up to 50A |
| Maximum DC Power | 725 W |
| Operating Case Temperature | -40 to 71°C |
| PWM Frequency | 40 kHz (Consult factory for PWM frequencies up to 100 kHz) |
| Efficiency | >95% (full load) |
| Feedbacks Supported | BiSS-C (Unidirectional), Quadrature Encoder, Resolver, Hall, Sensorless |
| Weight | 1.81 kg (4.0 lbs.) |
| Size | 6.00”L x 5.94”W x 2.50”H (152 mm x 151 mm x 63.5 mm) |
